A56-L-R-01-B-S-K-32 A56-L-R-01-C-S-K-32 Yuken brand plunger pump

A56-L-R-01-B-S-K-32  A56-L-R-01-C-S-K-32 Yuken brand Plunger pump

Features of A56 series YUKEN plunger pump:

1. High efficiency and low noise level

2. Low calorific value, realizing energy conservation

3. Inclined plate design, high volumetric efficiency and good sealing characteristics

4. Small power loss, low oil temperature rise and fall, optional small oil tank

5. A variety of control types, such as pressure compensator type, electromagnetic two pressure control type, proportional electro-hydraulic load sensing type, etc.

6. Various displacement, from 10cm3/rev to 219cm3/rev, can be applied to all large and small hydraulic oil stations.

A56-L-R-01-B-S-K-32

A56-L-R-01-C-S-K-32

A56-L-R-01-H-S-K-32

A56-F-R-01-B-S-K-32

A56-F-R-01-C-S-K-32

A56-F-R-01-H-S-K-32

Yuken plunger pump product classification:

AR series - compact and low noise

AR series - compact and low noise

AR series plunger pump is developed with the design concept of A series, which is famous for its high efficiency. The AR series is more compact in design, with reduced weight and noise level.

ARL1 series - minimum and lightest

ARL1 series - minimum and lightest

ARL1 series plunger pump is a compact, low noise, high efficiency, pressure compensated plunger pump. They are based on the mature technology and reliability of Yuken's A series/AR series piston pumps. These pumps cover a small displacement range from 6.2 to 16.3 cm3/rev.

Series A - Standard - Single

Series A - Standard - Single

Series A variable displacement piston pump is developed with Yuken's unique technology to meet customers' demands for energy efficiency and low noise solutions. These pumps support a variety of displacement sizes and control types and are widely used in various hydraulic systems

Series A - Standard - Double

Series A - Standard - Double

The A-Series piston pump offers two (2) dual pump options. One is the combination of piston pump+piston pump, and the other is the combination of piston pump+vane pump. They are driven by a motor to provide integrated flow for the hydraulic system and flow for different circuits.

A3H Series - High Voltage

A3H Series - High Voltage

A3H series variable piston pump is characterized by high pressure, high efficiency, high speed and low noise. They are applicable to engineering machinery and various industrial machinery, from presses to injection molding machines.

A3HG series - High voltage and straight drive

A3HG series - High voltage and straight drive

A3HG series pump is a high-pressure variable displacement plunger pump based on our prestigious "A3H" series pump, which conforms to international standards (ISO and SAE). These pumps have a through drive option that allows the auxiliary pump to be mounted on the back.

A3HM series - mobile pump

A3HM series - mobile pump

A3HM series pumps are engine driven high pressure and high speed pumps, which meet the requirements of the engineering vehicle market. maximum. The pressure is 35MPa (5075psi), and the maximum pressure is 35MPa (5075psi). Shaft speed (rpm) increases to 3400r/min
